As PCB designers, we often focus on layout and component selection, but understanding derating and uprating is crucial for ensuring the reliability and longevity of our designs throughout the PCB assembly process. Let’s dive into these practices and see how they impact our work.

Derating: Playing It Safe

Derating is all about operating components below their maximum rated capacity during PCB assembly and use. It’s like driving a car at 55 mph when it can go 100 mph – you’re reducing stress and extending its life.

Why should we care?

  1. Reliability Boost: By reducing stress on components, we’re essentially giving them an easier life. This means fewer failures during PCB assembly and longer operational life.
  2. Thermal Management: Lower voltage, current, or power means less heat. In our increasingly compact PCB assemblies, this is a big deal.
  3. Safety Margins: Operating below max ratings gives us a buffer against unexpected spikes or harsh conditions during PCB assembly and operation.

Real-world examples:

  • Using a 50V-rated capacitor in a 30V circuit
  • Running a 10A-rated motor at 8A
  • Keeping components well below their maximum temperature ratings during PCB assembly and use

Uprating: Pushing the Limits

Now, uprating is the opposite – using components beyond their specified limits in PCB assembly. It’s like overclocking a CPU. Risky, but sometimes necessary.

Why would we do this?

  1. Cost Savings: Sometimes, using a commercial-grade component and uprating it is cheaper than a specialized high-reliability part in PCB assembly.
  2. Availability: When that perfect component is out of stock, uprating a similar one might be the solution for your PCB assembly.
  3. Performance Needs: Occasionally, we need to squeeze extra performance out of a component in our PCB assembly.

But remember, uprating isn’t a decision to take lightly. It requires extensive testing and carries risks like reduced lifespan and potential failures in the final PCB assembly.

Practical Tips for PCB Designers and Assembly

Derating:

  • Always check the voltage, current, and temperature ratings of your components for PCB assembly.
  • Factor in worst-case scenarios in your calculations.
  • Use thermal simulation tools to identify potential hotspots in your PCB assembly.

Uprating:

  • Only consider it when absolutely necessary for your PCB assembly.
  • Conduct thorough testing under worst-case conditions.
  • Document all testing and decisions for traceability throughout the PCB assembly process.

In Sum

As PCB designers, we’re constantly balancing performance, cost, and reliability in our assemblies. Derating helps us err on the side of caution, while uprating gives us flexibility when needed. The key is knowing when and how to apply these practices effectively in PCB design and assembly.
